Extron DTP DVI 4K 230 Rx DTP Receiver for DVI

Extron DTP DVI 4K 230 Rx DTP Receiver for DVI- This is a refurbished item that comes with a 90-day exchange warranty. This has been serviced and calibrated to work as new. Servicing can include replacement of print heads, gears, rollers, cleaning and re-lubricating all internal mechanisms. Porter Electronics prides itself on only acquiring top quality used products that show minimal signs of use. Buying from Porter Electronics you should expect a very nice, refurbished unit. We do offer an extended warranty that can be purchased during checkout and will apply at the end of our already 90-day warranty.

Porter Electronics also offers free tech support for those needing extra help. We offer a free digital download of the manual for this product below. If you are unable to locate the link, just use our Contact Us page to request one.

Product Details - The Extron DTP DVI 4K 230 Rx is a digital twisted pair receiver that works with Extron DTP®‑enabled products to send DVI‑D video, audio, and bidirectional RS‑232 and IR signals up to 230 feet (70 meters) over a shielded CATx cable. It provides an economical and effective means for extending single link DVI‑D or HDMI signals. In addition, the DTP DVI 4K 230 Rx accepts analog stereo audio signals from a DTP‑enabled product over the same shielded twisted pair cable. It supports video signals at resolutions up to 4K. The compact enclosure size and remote power capability make the DTP DVI 4K 230 Rx ideal for discreet placement in lecterns, behind flat-panel displays, or wherever needed to meet application requirements.

The DTP DVI 4K 230 Rx enables the reliable transmission of DVI‑D signals, and is fully compatible with HDMI signals when used with the appropriate DVI-HDMI adapters from Extron. The twisted pair receiver can extend HDMI signals, supporting Deep Color up to 12‑bit, and embedded HD lossless audio formats. In addition, DDC communication of EDID and HDCP is continuously maintained between a source and display, ensuring direct compatibility and optimal signal transmission between devices. The DTP DVI 4K 230 Rx also receives stereo analog audio from a DTP‑enabled matrix switcher, switcher, or signal processor. The analog stereo audio signal is sent over the same shielded twisted pair cable as the DVI‑D and control signals, eliminating the need for a separate cable run to support analog audio at the receiver.

The twisted pair receiver provides other convenient, integrator-friendly features designed to help simplify installation. The DTP DVI 4K 230 Rx supports simultaneous transmission of bidirectional RS‑232 and IR signals from a control system for AV device control. Also, the receiver can be remotely powered over the shielded twisted pair cable by a DTP‑enabled product, allowing both devices to share one power supply.

The DTP DVI 4K 230 Rx can be integrated with an Extron DTP CrossPoint® Presentation Matrix Switcher, or other DTP‑enabled products to support displays and other output devices at remote locations. The receiver is housed in a 1" (2.5 cm) high, quarter rack width metal enclosure. The low profile design of the DTP DVI 4K 230 Rx allows for discreet placement in lecterns and behind flat-panel displays.

Extron recommends Extron-certified XTP DTP 24 shielded twisted pair cable, shielded RJ‑45 plugs, jacks, and couplers engineered for optimum signal transmission with Extron DTP Series products. The XTP DTP 24 cable is certified to 475 MHz, and utilizes a SF/UTP design with four unshielded 24 AWG twisted pair conductors inside an overall braid and foil shield for superior performance and noise immunity.

• Receives single link DVI-D plus control and analog audio up to 230 feet (70 meters) over a shielded CATx cable — The DTP DVI 4K 230 Rx provides high reliability and maximum performance on an economical and easily installed cable infrastructure.
• Input: One DTP® 230 twisted pair input on RJ-45
• Outputs: One DVI-D, stereo audio on captive screw
• Supports computer and video resolutions up to 4K — Supports 4K/60 4:2:0 and 4K/30 4:4:4, maintaining superior image quality at the highest resolutions. Pixel clocks above 165 MHz are supported in HDMI format.
• Supported HDMI specification features include data rates up to 10.2 Gbps, Deep Color up to 12-bit, 3D, and HD lossless audio formats
• HDCP 2.3 compliant — Ensures display of content-protected 4K video media and maintains interoperability with earlier versions of HDCP.
• Remote power capability — For simplified installation, the receiver can be remotely powered by a DTP‑enabled product over the twisted pair connection.
• Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance
• Compatible with CATx shielded twisted pair cable — Shielded twisted pair cabling with solid center conductor sizes of 24 AWG or better is recommended for optimal performance.
• Accepts additional analog stereo audio signals — The DTP DVI 4K 230 Rx accepts stereo analog audio from a DTP‑enabled product. Embedded digital audio is not de‑embedded from the digital video signal.
• Bidirectional RS-232 and IR pass-through for AV device control — Bidirectional RS-232 control and IR signals can be transmitted alongside the video signal, allowing remote AV devices to be controlled without the need for additional cabling.
• Supports EDID and HDCP transmission — DDC channels are actively buffered, allowing continuous communication between source and display.
• Compatible with all DTP 230 Series transmitters and DTP-enabled products — Enables mixing and matching with desktop and wallplate transmitters, as well as other DTP-enabled products to meet application requirements.
• LED indicator for signal presence and power — Provides visual indication of system status for real-time feedback and monitoring of key performance parameters.
• RJ-45 signal and link LED indicators for DTP port — Provides a means for validating signal flow and operation, allowing quick identification of connectivity issues.
• Supports HDMI signals when used with optional Extron DVI-HDMI adapters
• UL 2043 plenum rated — The DTP DVI 4K 230 Rx meets UL 2043 for smoke and heat release for installation within a plenum airspace above a drop ceiling - power supply excluded. Above-the-ceiling placement conceals the receiver to prevent theft, and is convenient for installing equipment when space inside the room is limited.
• JITC Certified — Successfully completed interoperability and information assurance testing for use in government applications and other mission-critical environments.
• 1" (2.5 cm) high, quarter rack width metal enclosure — With a low profile enclosure, the device can be installed discreetly wherever needed.
• Optional, external Extron Everlast™ power supply available, part #70-1174-01 — Provides worldwide power compatibility with high demonstrated reliability and low power consumption
